AH183-PL-A - Diodes Incorporated

AH183-PL-A Details

• Manufacturer Part Number:

  AH183-PL-A

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  ROHS COMPLIANT, SIP-3

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• Manufacturer:

  Diodes Incorporated

• YTEOL:

  0

• Additional Feature:

  BATTERY OPERATION

• Body Breadth:

  1.5 mm

• Body Height:

  3 mm

• Body Length or Diameter:

  4.1 mm

• Housing:

  PLASTIC

• Hysteresis:

  1 mT

• JESD-609 Code:

  e3

• Magnetic Field Range-Max:

  6 mT

• Magnetic Field Range-Min:

  1 mT

• Mounting Feature:

  THROUGH HOLE MOUNT

• Number of Terminals:

  3

• Operating Current-Max:

  2 mA

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Range:

  0.30V

• Output Type:

  ANALOG VOLTAGE

• Package Shape/Style:

  RECTANGULAR

• Sensors/Transducers Type:

  MAGNETIC FIELD SENSOR,HALL EFFECT

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  2.5 V

• Surface Mount:

  NO

• Terminal Finish:

  MATTE TIN

• Termination Type:

  SOLDER
