AHC0609150M063R - Kyocera AVX

AHC0609150M063R Details

• Manufacturer Part Number:

  AHC0609150M063R

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  CHIP

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• Manufacturer:

  Kyocera AVX Components

• YTEOL:

  0

• Additional Feature:

  ESR IS MEASURED AT 100 KHZ

• Capacitance:

  15 µF

• Capacitor Type:

  ALUMINUM ELECTROLYTIC CAPACITOR

• Dielectric Material:

  ALUMINUM (WET)

• ESR:

  100 mΩ

• Height:

  9.3 mm

• JESD-609 Code:

  e3

• Leakage Current:

  0.0095 mA

• Length:

  6.6 mm

• Mounting Feature:

  SURFACE MOUNT

• Negative Tolerance:

  20%

• Number of Terminals:

  2

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Style:

  SMT

• Packing Method:

  TR, 15 INCH

• Polarity:

  POLARIZED

• Positive Tolerance:

  20%

• Rated (DC) Voltage (URdc):

  63 V

• Ripple Current:

  40 mA

• Size Code:

  2626

• Surface Mount:

  YES

• Tan Delta:

  0.12

• Terminal Finish:

  Tin (Sn)

• Terminal Shape:

  FLAT

• Width:

  6.6 mm
