AIF25H300-L - Advanced Energy

AIF25H300-L Details

• Manufacturer Part Number:

  AIF25H300-L

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-22

• ECCN Code:

  EAR99

• Manufacturer:

  Advanced Energy Industries Inc

• YTEOL:

  9

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CE; CUL; EN; UL; TUV; UKCA

• Efficiency (Main Output):

  90%

• Input Voltage-Max:

  420 V

• Input Voltage-Min:

  250 V

• Input Voltage-Nom:

  300 V

• JESD-30 Code:

  R-XXMA-X22

• Length:

  116.8 mm

• Line Regulation-Max:

  0.2%

• Load Regulation-Max:

  0.2%

• Number of Functions:

  1

• Number of Outputs:

  1

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -20 °C

• Output Current-Max:

  25 A

• Output Voltage-Max:

  28.8 V

• Output Voltage-Min:

  19.2 V

• Output Voltage-Nom:

  24 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  XMA

• Package Equivalence Code:

  MODULE,22LEAD(UNSPEC)

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER CURRENT; OVER VOLTAGE; OVER TEMPERATURE

• Ripple Voltage (Main Out):

  0.16968 Vrms

• Screening Level:

  EN/UL 62368-1

• Seated Height-Max:

  14.21 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  UNSPECIFIED

• Total Power Output-Max:

  600 W

• Trim/Adjustable Output:

  YES

• Width:

  61 mm
