AIRD-03-121K Frequently Asked Questions (FAQs)

• What is the recommended PCB land pattern for the AIRD-03-121K?
  Abracon recommends a land pattern with a minimum pad size of 1.3mm x 0.8mm and a non-solder mask defined (NSMD) pad shape to ensure reliable soldering and to prevent solder bridging.
• How do I handle the AIRD-03-121K during assembly to prevent damage?
  Handle the AIRD-03-121K by the edges or the body, avoiding touching the pins or the ceramic resonator. Use an anti-static wrist strap or mat to prevent electrostatic discharge (ESD) damage.
• What is the maximum operating temperature range for the AIRD-03-121K?
  The AIRD-03-121K can operate safely within a temperature range of -40°C to +85°C. However, the frequency stability and accuracy may degrade at extreme temperatures.
• Can I use the AIRD-03-121K in a humid or high-moisture environment?
  The AIRD-03-121K is not designed for use in humid or high-moisture environments. Abracon recommends using a conformal coating or encapsulation to protect the device from moisture and humidity.
• How do I troubleshoot issues with the AIRD-03-121K, such as frequency drift or instability?
  Check the PCB layout and design for any issues, such as poor grounding, noise coupling, or inadequate decoupling. Verify that the device is properly soldered and that the surrounding components are not causing interference. Consult Abracon's application notes and technical support for further assistance.
