AIRD-06-471K footprint, schematic symbol and 3D model by ABRACON

Symbol

PCB Footprints

3D Models

AIRD-06-471K Details

Abracon recommends a land pattern with a pad size of 1.3mm x 0.8mm and a spacing of 1.5mm between pads to ensure reliable soldering and minimize thermal resistance.
Yes, the AIRD-06-471K is rated for operation up to 125°C, making it suitable for high-temperature applications. However, derating may be necessary for extended operation at high temperatures.
The maximum current rating for the AIRD-06-471K is 1.5A, but it's recommended to derate the current to 1A or less for reliable operation and to minimize self-heating.
Yes, the AIRD-06-471K is compatible with lead-free soldering processes and meets the requirements of the RoHS directive.
The typical tolerance for the inductance value of the AIRD-06-471K is ±10%, but this can vary depending on the specific batch and manufacturing process.

Manufacturer Collaborated

System Verified

Community Approved

Use the download button to access the AIRD-06-471K schematic symbol, PCB footprint, and 3D model.

To find more CAD model downloads similar to this part, try a partial part number search, like AIRD-, or try a keyword search, such as Fixed Inductors
