AK5DBF1-122.8800T2 - ABRACON

AK5DBF1-122.8800T2 Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal performance?
  Abracon recommends a symmetrical PCB layout with a solid ground plane, and the oscillator should be placed as close as possible to the microcontroller or IC. A minimum of 2-layer PCB is recommended, with the oscillator on the top layer and the ground plane on the bottom layer.
• How do I ensure the oscillator starts up correctly?
  To ensure proper startup, Abracon recommends applying power to the oscillator slowly (dv/dt < 10V/ms) and ensuring that the power supply is stable and noise-free. Additionally, the oscillator should be decoupled from the power supply with a 10nF to 100nF capacitor.
• What is the maximum operating temperature range for this oscillator?
  The AK5DBF1-122.8800T2 has an operating temperature range of -40°C to +85°C, but it's recommended to operate within -20°C to +70°C for optimal performance and reliability.
• Can I use this oscillator in a high-vibration environment?
  While the AK5DBF1-122.8800T2 is designed to be rugged, it's still a crystal oscillator and may not perform well in extremely high-vibration environments. Abracon recommends evaluating the oscillator's performance in the specific application environment to ensure reliability.
• What is the recommended storage condition for this oscillator?
  Abracon recommends storing the AK5DBF1-122.8800T2 in a dry, cool place (temperature range: -20°C to +40°C, humidity < 60%) to prevent damage or degradation.
