AK5DBF1-125.0000T2 Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal performance?
  Abracon recommends a symmetrical PCB layout with a solid ground plane, and the oscillator should be placed as close as possible to the microcontroller or IC. A minimum of 2-layer PCB is recommended, with the oscillator on the top layer and the ground plane on the bottom layer.
• How do I ensure the oscillator starts up reliably?
  To ensure reliable startup, Abracon recommends a power-up ramp time of 1ms to 10ms, and a power supply voltage that is within the specified operating range. Additionally, the oscillator should be decoupled from the power supply with a 10nF to 100nF capacitor.
• What is the maximum operating temperature range for this oscillator?
  The AK5DBF1-125.0000T2 has an operating temperature range of -40°C to +85°C, but it's recommended to derate the frequency tolerance by 5ppm/°C for temperatures above 70°C.
• Can I use this oscillator in a high-vibration environment?
  The AK5DBF1-125.0000T2 is designed to withstand vibrations up to 10g peak acceleration, but it's recommended to consult with Abracon's application engineers for specific vibration requirements and to ensure the oscillator is properly mounted and secured.
• What is the recommended storage condition for this oscillator?
  Abracon recommends storing the AK5DBF1-125.0000T2 in a dry, cool place with a relative humidity of 60% or less, and at a temperature range of -40°C to +30°C. The oscillator should be stored in its original packaging or in a similar ESD-protective package.
