AK7DCF1-156.2500T - ABRACON

AK7DCF1-156.2500T Details

• Manufacturer Part Number:

  AK7DCF1-156.2500T

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Factory Lead Time:

  14 Weeks

• Manufacturer:

  Abracon Corporation

• YTEOL:

  6

• Additional Feature:

  ENABLE/DISABLE FUNCTION; COMPLEMENTARY OUTPUT; TR, 7 INCH

• Fall Time-Max:

  0.5 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  25%

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  6

• Operating Frequency-Nom:

  156.25 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  LVDS

• Output Load:

  100 OHM

• Physical Dimension:

  7.0mm x 5.0mm x 1.8mm

• Rise Time-Max:

  0.5 ns

• Supply Voltage-Max:

  1.89 V

• Supply Voltage-Min:

  1.71 V

• Supply Voltage-Nom:

  1.8 V

• Surface Mount:

  YES

• Symmetry-Max:

  55/45 %
