AL1692S-13 - Diodes Incorporated

Description: LED Driver IC 1 Output AC DC Offline Switcher Flyback, Step-Down (Buck), Step-Up (Boost) Triac Dimming 8-SO

Download AL1692S-13 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
AL1692S-13 - Diodes Incorporated PCB footprint - Small Outline Packages - Small Outline Packages - SO-8_2024 -1
click to zoom
3D Models
AL1692S-13 - Diodes Incorporated  - 3D model - Small Outline Packages - SO-8_2024 -1
click to zoom

AL1692S-13 Details

  • Manufacturer Part Number:

    AL1692S-13

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    SOP-8

  • Country Of Origin:

    Mainland China

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    12 Weeks

  • Manufacturer:

    Diodes Incorporated

  • YTEOL:

    8

  • Interface IC Type:

    LED DISPLAY DRIVER

  • JESD-30 Code:

    R-PDSO-G8

  • JESD-609 Code:

    e3

  • Length:

    4.9 mm

  • Number of Functions:

    1

  • Number of Segments:

    2

  • Number of Terminals:

    8

  • Operating Temperature-Max:

    105 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    LSOP

  • Package Equivalence Code:

    SOP8,.25

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, LOW PROFILE

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    1.5 mm

  • Surface Mount:

    YES

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    MATTE TIN

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    3.9 mm

AL1692S-13 Frequently Asked Questions (FAQs)

  • A thermal pad is recommended under the IC to improve heat dissipation. A minimum of 2oz copper thickness and a thermal relief pattern are suggested. Refer to the application note AN-114 for more details.
  • Ensure the input voltage is within the recommended range (4.5V to 18V), and the output capacitor is a low-ESR type (e.g., X5R or X7R) with a minimum capacitance of 10uF. Also, ensure the feedback resistors are 1% tolerance or better.
  • The maximum output current is 1.5A, but it's recommended to derate the output current based on the ambient temperature and PCB thermal design. Refer to the thermal derating curve in the datasheet for more information.
  • The AL1692S-13 is rated for operation up to 125°C, but the output current and voltage regulation may be affected at high temperatures. Ensure proper thermal design and derating to ensure reliable operation.
  • Use a TVS diode or a transient voltage suppressor in parallel with the input capacitor to protect the IC from voltage surges or spikes. Ensure the TVS diode is rated for the maximum input voltage and has a response time faster than the AL1692S-13's internal overvoltage protection.
