AL1793AFE-13 - Diodes Incorporated

Description: LED Driver IC 3 Output Linear Analog, PWM Dimming 500mA U-DFN4030-14

Download AL1793AFE-13 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
AL1793AFE-13 - Diodes Incorporated PCB footprint - Other - Other - AL1793AFE-13
click to zoom
3D Models
AL1793AFE-13 - Diodes Incorporated  - 3D model - Other - AL1793AFE-13
click to zoom

AL1793AFE-13 Details

  • Manufacturer Part Number:

    AL1793AFE-13

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    DFN-14

  • Country Of Origin:

    Mainland China

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    12 Weeks

  • Manufacturer:

    Diodes Incorporated

  • YTEOL:

    8

  • Interface IC Type:

    LED DISPLAY DRIVER

  • JESD-30 Code:

    R-PDSO-N14

  • Length:

    4 mm

  • Multiplexed Display Capability:

    NO

  • Number of Functions:

    1

  • Number of Segments:

    9

  • Number of Terminals:

    14

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HVSON

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    0.65 mm

  • Supply Voltage-Max:

    30 V

  • Supply Voltage-Min:

    6.5 V

  • Supply Voltage-Nom:

    12 V

  • Surface Mount:

    YES

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    DUAL

  • Width:

    3 mm

AL1793AFE-13 Frequently Asked Questions (FAQs)

  • A thermal pad is recommended to be connected to a large copper area on the PCB to dissipate heat efficiently. A minimum of 2oz copper thickness is recommended.
  • Ensure that the input voltage is within the recommended range, and the output capacitor is of sufficient value (at least 10uF) and low ESR. Also, ensure that the feedback pin is properly connected to the output voltage.
  • The maximum ambient temperature for reliable operation is 85°C, but it's recommended to keep it below 70°C for optimal performance and reliability.
  • Yes, but ensure that the device is properly secured to the PCB and the PCB is securely fastened to the system. Also, consider using a vibration-resistant capacitor for the output capacitor.
  • Use a voltage supervisor or a reset IC to monitor the input voltage and reset the system if it goes out of range. Also, consider adding overvoltage protection (OVP) and undervoltage protection (UVP) circuits.
