AL8806QMP-13 - Diodes Incorporated

AL8806QMP-13 Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal thermal performance?
  A thermal pad is recommended to be connected to a large copper area on the PCB to dissipate heat. The copper area should be at least 1 inch x 1 inch in size and should be connected to a ground plane to minimize thermal resistance.
• How do I ensure the device is not damaged during soldering?
  The device is sensitive to excessive heat and moisture. To prevent damage, follow the recommended soldering profile: peak temperature 260°C, time above 217°C 30s, and moisture sensitivity level (MSL) 3.
• What is the maximum allowed voltage on the input pin?
  The maximum allowed voltage on the input pin is 6.5V. Exceeding this voltage may damage the device.
• Can I use this device in a high-temperature environment?
  The device is rated for operation up to 125°C. However, the maximum junction temperature (TJ) should not exceed 150°C. Ensure proper thermal design and heat sinking to prevent overheating.
• How do I calculate the output voltage ripple?
  The output voltage ripple can be calculated using the formula: ΔVout = (Iout x Rcoil) / (L x fsw), where Iout is the output current, Rcoil is the coil resistance, L is the inductance, and fsw is the switching frequency.
