AL8821SP-13 - Diodes Incorporated

Description: LED Lighting Drivers 40V 2A Boost LED Driver 5V to 36V

Download AL8821SP-13 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
AL8821SP-13 - Diodes Incorporated PCB footprint - Small Outline Packages - Small Outline Packages - AL8821SP-13
click to zoom
3D Models
AL8821SP-13 - Diodes Incorporated  - 3D model - Small Outline Packages - AL8821SP-13
click to zoom

AL8821SP-13 Details

  • Manufacturer Part Number:

    AL8821SP-13

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    Diodes Incorporated

  • YTEOL:

    0

  • Additional Feature:

    HAS SUPPLY VOLTAGE RANGING FROM 4.5 TO 5 V FOR INTERNAL CIRCUITS

  • Interface IC Type:

    LED DISPLAY DRIVER

  • JESD-30 Code:

    R-PDSO-G8

  • JESD-609 Code:

    e3

  • Length:

    4.9 mm

  • Number of Functions:

    1

  • Number of Segments:

    2

  • Number of Terminals:

    8

  • Operating Temperature-Max:

    105 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HLSOP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, HEAT SINK/SLUG, LOW PROFILE

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    1.7 mm

  • Supply Voltage-Max:

    36 V

  • Supply Voltage-Min:

    5 V

  • Surface Mount:

    YES

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    MATTE TIN

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Width:

    3.9 mm

AL8821SP-13 Frequently Asked Questions (FAQs)

  • A thermal pad is recommended to be connected to a large copper area on the PCB to dissipate heat. The copper area should be at least 1 inch x 1 inch in size and connected to a ground plane to ensure good thermal conductivity.
  • The device requires a bias voltage of 5V to 12V on the VIN pin, and a decoupling capacitor of 1uF to 10uF should be placed close to the VIN pin to ensure stable operation.
  • The maximum current rating for the output pins is 1.5A per pin, but it's recommended to derate the current to 1A per pin for reliable operation.
  • An overvoltage protection (OVP) circuit can be implemented using a zener diode and a resistor to clamp the input voltage to a safe level. An undervoltage lockout (UVLO) circuit can be implemented using a voltage supervisor IC to prevent the device from operating outside its specified voltage range.
  • A TVS (transient voltage suppressor) diode or a zener diode can be used to protect the device from electrostatic discharge (ESD) events. The TVS diode should be rated for the maximum voltage and current of the device.
