AM29BL802CB-65RZF - AMD

AM29BL802CB-65RZF Details

• Manufacturer Part Number:

  AM29BL802CB-65RZF

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• ECCN Code:

  EAR99

• HTS Code:

  8542.32.00.51

• Manufacturer:

  AMD

• Access Time-Max:

  65 ns

• Boot Block:

  BOTTOM

• Command User Interface:

  YES

• Data Polling:

  YES

• JESD-30 Code:

  R-PDSO-G56

• Memory Density:

  8388608 bit

• Memory IC Type:

  FLASH

• Memory Width:

  16

• Number of Sectors/Size:

  1,2,1,3,2

• Number of Terminals:

  56

• Number of Words:

  524288 words

• Number of Words Code:

  512000

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Organization:

  512KX16

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SSOP

• Package Equivalence Code:

  SOP56,.6,32

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, SHRINK PITCH

• Parallel/Serial:

  PARALLEL

• Qualification Status:

  Not Qualified

• Ready/Busy:

  YES

• Sector Size:

  8K,4K,48K,64K,128K

• Standby Current-Max:

  0.00001 A

• Supply Current-Max:

  0.04 mA

• Supply Voltage-Nom (Vsup):

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.8 mm

• Terminal Position:

  DUAL

• Toggle Bit:

  YES

• Type:

  NOR TYPE
