AM53CF96KC - AMD

AM53CF96KC Details

• Manufacturer Part Number:

  AM53CF96KC

• Pbfree Code:

  No

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  QFP

• Package Description:

  METRIC, PLASTIC, QFP-100

• Pin Count:

  100

• ECCN Code:

  3A991.a.2

• HTS Code:

  8542.31.00.30

• Manufacturer:

  AMD

• YTEOL:

  0

• Address Bus Width:

  8

• Clock Frequency-Max:

  40 MHz

• Data Transfer Rate-Max:

  10 MBps

• External Data Bus Width:

  8

• JESD-30 Code:

  R-PQFP-F100

• JESD-609 Code:

  e0

• Length:

  20 mm

• Moisture Sensitivity Level:

  3

• Number of Terminals:

  100

• Operating Temperature-Max:

  70 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  GQFF

• Package Equivalence Code:

  TPAK100,1.4SQ,25

• Package Shape:

  RECTANGULAR

• Package Style:

  FLATPACK, GUARD RING

• Qualification Status:

  Not Qualified

• Supply Current-Max:

  30 mA

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  4.5 V

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  FLAT

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  QUAD

• Width:

  14 mm

• uPs/uCs/Peripheral ICs Type:

  BUS CONTROLLER, SCSI
