TE Connectivity recommends a minimum clearance of 10mm around the antenna to ensure optimal performance. The PCB layout should also avoid placing high-frequency components or traces near the antenna to minimize interference.
Yes, the ANT-433-HETH antenna is designed to operate in harsh environments, including high temperatures, humidity, and vibration. However, it's essential to follow the recommended installation and mounting guidelines to ensure reliable performance.
The ANT-433-HETH antenna has a Hirose U.FL connector, which requires a compatible mating connector on the PCB. Ensure proper mating and secure connection to prevent signal loss and damage to the antenna.
The ANT-433-HETH antenna has a monopole-like radiation pattern, with a maximum gain of around 2dBi. The radiation pattern is omnidirectional, making it suitable for applications where the antenna needs to communicate with devices in multiple directions.
The ANT-433-HETH antenna is designed to operate in the 433MHz frequency band, which is commonly used in IoT, industrial, and medical applications. Ensure that your device operates within this frequency band for optimal performance.
