AP2401S-13 - Diodes Incorporated

Description: DiodesZetex AP2401S-13, Dual USB Power Switch, High Side, 135mΩ, 2.7 V min., 8-Pin SOIC

Download AP2401S-13 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
AP2401S-13 - Diodes Incorporated PCB footprint - Small Outline Packages - Small Outline Packages - SO-8
click to zoom
3D Models
AP2401S-13 - Diodes Incorporated  - 3D model - Small Outline Packages - SO-8
click to zoom

AP2401S-13 Details

  • Manufacturer Part Number:

    AP2401S-13

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    SOIC

  • Package Description:

    SOP-8

  • Pin Count:

    8

  • Country Of Origin:

    Mainland China

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    12 Weeks

  • Manufacturer:

    Diodes Incorporated

  • YTEOL:

    7

  • Adjustable Threshold:

    NO

  • Analog IC - Other Type:

    LOAD SWITCH
