Diodes Incorporated recommends a PCB layout with a solid ground plane, minimal thermal vias, and a heat sink attached to the exposed pad for optimal thermal performance.
To ensure proper biasing, follow the recommended operating conditions in the datasheet, including the input voltage range, output voltage range, and quiescent current. Additionally, ensure the input and output capacitors are properly selected and placed.
To minimize EMI and noise, use a shielded layout, keep the switching node (SW) away from sensitive nodes, use a common-mode choke, and add a filter capacitor at the output. Additionally, ensure the device is properly decoupled and the PCB is well-grounded.
Select input and output capacitors based on the recommended values in the datasheet, considering factors such as capacitance, ESR, and voltage rating. Ensure the capacitors are placed close to the device and have a low ESL to minimize noise and ringing.
For high-power applications, ensure the device is attached to a heat sink with a thermal interface material, and the PCB is designed with thermal vias and a solid ground plane. Additionally, consider using a thermal pad or a heat sink with a high thermal conductivity.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
AP64502SP-13 Overview
Use the download button to access the AP64502SP-13 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like AP645,
or try a keyword search, such as Switching Regulator or Controllers
