APTM50H15FT1G - Microsemi Corporation

APTM50H15FT1G Details

• Manufacturer Part Number:

  APTM50H15FT1G

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Package Description:

  ROHS COMPLIANT PACKAGE-12

• Pin Count:

  12

• ECCN Code:

  EAR99

• Manufacturer:

  Microsemi Corporation (now Microchip)

• Additional Feature:

  AVALANCHE RATED

• Case Connection:

  ISOLATED

• Configuration:

  COMPLEX

• DS Breakdown Voltage-Min:

  500 V

• Drain Current-Max (ID):

  25 A

• Drain-source On Resistance-Max:

  0.156 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• JESD-30 Code:

  R-XUFM-X12

• Number of Elements:

  4

• Number of Terminals:

  12

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  150 °C

• Package Body Material:

  UNSPECIFIED

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  208 W

• Pulsed Drain Current-Max (IDM):

  135 A

• Qualification Status:

  Not Qualified

• Surface Mount:

  NO

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  UPPER

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
