Store the AQH3213A in a dry, cool place away from direct sunlight, with a temperature range of 5°C to 30°C and humidity below 70%. Avoid storing in areas with high temperatures, high humidity, or corrosive substances.
Handle the AQH3213A by the body, avoiding touching the pins or electrical components. Use an anti-static wrist strap or mat to prevent electrostatic discharge. Avoid bending, flexing, or applying excessive force to the component.
The recommended soldering temperature is 250°C (max) for 3 seconds (max) using a soldering iron. For reflow soldering, use a temperature profile with a peak temperature of 240°C (max) and a total process time of 120 seconds (max).
While the AQH3213A is designed to withstand some vibration, it's essential to evaluate the specific vibration requirements of your application. Panasonic recommends consulting the datasheet and performing reliability tests to ensure the component meets your application's vibration requirements.
Use a soft, dry brush or a lint-free cloth to gently remove any debris or dust from the AQH3213A. Avoid using chemicals, solvents, or ultrasonic cleaning methods, as they may damage the component.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
AQH3213A Overview
Use the download button to access the AQH3213A schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like AQH32,
or try a keyword search, such as Solid State Relays
