AQW212EH - Panasonic

Description: DPST-NO Solid State Relay Through Hole 500 mA PCB Mount PhotoMOS, 1.5 V

Download AQW212EH Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
AQW212EH - Panasonic PCB footprint - Dual-In-Line Packages - Dual-In-Line Packages - 8-Pin DIP
click to zoom
3D Models
AQW212EH - Panasonic  - 3D model - Dual-In-Line Packages - 8-Pin DIP
click to zoom

AQW212EH Details

  • Manufacturer Part Number:

    AQW212EH

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • HTS Code:

    8541.40.95.00

  • Factory Lead Time:

    14 Weeks

  • Manufacturer:

    Panasonic Electronic Components

  • YTEOL:

    5.59

  • Configuration:

    SEPARATE, 2 ELEMENTS

  • Forward Current-Max:

    0.05 A

  • Isolation Voltage-Max:

    5000 V

  • Number of Elements:

    2

  • On-State Current-Max:

    0.6 A

  • On-state Resistance-Max:

    2.5 Ω

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Optoelectronic Device Type:

    TRANSISTOR OUTPUT SSR

  • Packing Method:

    TUBE
