AQW414EHAZ - Panasonic

AQW414EHAZ Details

• Manufacturer Part Number:

  AQW414EHAZ

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SMT, DIP-8

• HTS Code:

  8541.40.95.00

• Manufacturer:

  Panasonic Electronic Components

• YTEOL:

  5.59

• Additional Feature:

  UL RECOGNIZED

• Configuration:

  SEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE

• Control Current:

  0.0013 A

• Control Voltage:

  1.14 V

• Forward Current-Max:

  0.05 A

• Input Type:

  AC/DC

• Isolation Voltage-Max:

  5000 V

• Mounting Feature:

  SURFACE MOUNT

• Number of Elements:

  2

• On-State Current-Max:

  0.13 A

• On-state Resistance-Max:

  35 Ω

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Optoelectronic Device Type:

  TRANSISTOR OUTPUT SSR

• Output Circuit Type:

  MOSFET

• Overall Height:

  2.9 mm

• Overall Length:

  9.86 mm

• Packing Method:

  TR

• Surface Mount:

  YES
