ARJM21A1-547-AB-EW2 - ABRACON

ARJM21A1-547-AB-EW2 Details

• Manufacturer Part Number:

  ARJM21A1-547-AB-EW2

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Factory Lead Time:

  15 Weeks

• Manufacturer:

  Abracon Corporation

• YTEOL:

  8

• Additional Feature:

  STACKED, 2 PORT, 8-POSITION EACH

• Board Mounting Option:

  HOLE .125-.137

• Body Breadth:

  1.004 inch

• Body Depth:

  1.108 inch

• Body Length:

  0.676 inch

• Connector Type:

  RJ CONNECTOR

• Contact Gender:

  FEMALE AND FEMALE

• Contact Pattern:

  RECTANGULAR

• Contact Style:

  TELCOM, MODULAR

• Empty Shell:

  NO

• Filter Feature:

  YES

• Insulator Color:

  BLACK

• Insulator Material:

  POLYBUTYLENE TEREPHTHALATE

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of PCB Rows:

  2+2

• Number of Ports:

  2

• Number of Rows Loaded:

  1+1

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  STAGGERED

• PCB Contact Row Spacing:

  1.27/4.06 mm

• Plating Thickness:

  6u inch

• Polarization Key:

  POLARIZED HOUSING

• Reference Standard:

  UL

• Shell Finish:

  NICKEL

• Shell Material:

  BRASS

• Terminal Length:

  0.12 inch

• Terminal Pitch:

  2.54 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  16

• UL Flammability Code:

  94V-0
