AS1C512K16P-70BIN - Alliance Memory

AS1C512K16P-70BIN Details

• Manufacturer Part Number:

  AS1C512K16P-70BIN

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  FPBGA-48

• Country Of Origin:

  South Korea

• ECCN Code:

  3A991.b.2.a

• HTS Code:

  8542.32.00.41

• Factory Lead Time:

  20 Weeks

• Manufacturer:

  Alliance Memory Inc

• YTEOL:

  0

• Access Time-Max:

  70 ns

• JESD-30 Code:

  R-PBGA-B48

• Length:

  7 mm

• Memory Density:

  8388608 bit

• Memory IC Type:

  PSEUDO STATIC RAM

• Memory Width:

  16

• Moisture Sensitivity Level:

  3

• Number of Functions:

  1

• Number of Terminals:

  48

• Number of Words:

  524288 words

• Number of Words Code:

  512000

• Operating Mode:

  ASYNCHRONOUS

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Organization:

  512KX16

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  VFBGA

• Package Shape:

  RECTANGULAR

• Package Style:

  GRID ARRAY, VERY THIN PROFILE, FINE PITCH

• Parallel/Serial:

  PARALLEL

• Seated Height-Max:

  0.97 mm

• Supply Voltage-Max (Vsup):

  3.3 V

• Supply Voltage-Min (Vsup):

  2.6 V

• Supply Voltage-Nom (Vsup):

  3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  BALL

• Terminal Pitch:

  0.75 mm

• Terminal Position:

  BOTTOM

• Width:

  6 mm
