ASEMPLV-10.000MHZ-LR - ABRACON

ASEMPLV-10.000MHZ-LR Details

• Manufacturer Part Number:

  ASEMPLV-10.000MHZ-LR

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Manufacturer:

  Abracon Corporation

• YTEOL:

  6

• Frequency Stability:

  25%

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  6

• Operating Frequency-Max:

  460 MHz

• Operating Frequency-Min:

  10 MHz

• Operating Frequency-Nom:

  10 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  LVDS

• Output Load:

  100 OHM

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  SOLCC6,.1,40

• Physical Dimension:

  3.2mm x 2.5mm x 0.85mm

• Qualification Status:

  Not Qualified

• Supply Current-Max:

  40 mA

• Supply Voltage-Max:

  3.6 V

• Supply Voltage-Min:

  2.25 V

• Surface Mount:

  YES

• Symmetry-Max:

  52/48 %

• Technology:

  CMOS

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)
