ASFLMPLV-155.520MHZ-LY - ABRACON

ASFLMPLV-155.520MHZ-LY Details

• Manufacturer Part Number:

  ASFLMPLV-155.520MHZ-LY

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Thailand

• Manufacturer:

  Abracon Corporation

• YTEOL:

  6.5

• Frequency Stability:

  10%

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  6

• Operating Frequency-Max:

  460 MHz

• Operating Frequency-Min:

  10 MHz

• Operating Frequency-Nom:

  155.52 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  LVDS

• Output Load:

  50 OHM, 2 pF

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  SOLCC6,.12

• Physical Dimension:

  5.0mm x 3.2mm x 0.85mm

• Qualification Status:

  Not Qualified

• Supply Current-Max:

  32 mA

• Supply Voltage-Max:

  3.6 V

• Supply Voltage-Min:

  2.25 V

• Surface Mount:

  YES

• Symmetry-Max:

  52/48 %

• Technology:

  CMOS

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)
