ASTX-13-A-19.200MHZ-T - ABRACON

ASTX-13-A-19.200MHZ-T Details

• Manufacturer Part Number:

  ASTX-13-A-19.200MHZ-T

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  SMD, 4 PIN

• Country Of Origin:

  Taiwan

• Manufacturer:

  Abracon Corporation

• YTEOL:

  0

• Aging:

  1 PPM/FIRST YEAR

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  1.5%

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  4

• Operating Frequency-Nom:

  19.2 MHz

• Operating Temperature-Max:

  75 °C

• Operating Temperature-Min:

  -30 °C

• Oscillator Type:

  CLIPPED SINE

• Output Impedance:

  10000 Ω

• Output Level:

  0.8 V

• Package Equivalence Code:

  LCC4,.06X.08,63/40

• Packing Method:

  TR, 7 INCH

• Physical Dimension:

  2.0mm x 1.6mm x 0.8mm

• Supply Voltage-Max:

  3.15 V

• Supply Voltage-Min:

  2.85 V

• Supply Voltage-Nom:

  3 V

• Surface Mount:

  YES

• Terminal Finish:

  Gold (Au) - with Nickel (Ni) barrier
