ASVMB-14.31818MHZ-XY-T - ABRACON

ASVMB-14.31818MHZ-XY-T Details

• Manufacturer Part Number:

  ASVMB-14.31818MHZ-XY-T

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT, ULTRA MINIATURE, PLASTIC, QFN-4

• Country Of Origin:

  Thailand

• Factory Lead Time:

  8 Weeks

• Manufacturer:

  Abracon Corporation

• YTEOL:

  6.5

• Additional Feature:

  TRI-STATE; STANDBY; ENABLE/DISABLE FUNCTION; TR; SUPPLY VOLTAGE 1.8V AND 2.5V ALSO AVAILABLE

• Fall Time-Max:

  2 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  10%

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  4

• Operating Frequency-Nom:

  14.31818 MHz

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  CMOS

• Output Load:

  15 pF

• Package Body Material:

  PLASTIC/EPOXY

• Physical Dimension:

  7.0mm x 5.0mm x 0.85mm

• Rise Time-Max:

  2 ns

• Supply Voltage-Max:

  3.3 V

• Supply Voltage-Min:

  1.8 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Symmetry-Max:

  55/45 %

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)
