ASVMPC-25.000MHZ-LR-T - ABRACON

ASVMPC-25.000MHZ-LR-T Details

• Manufacturer Part Number:

  ASVMPC-25.000MHZ-LR-T

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  QFN, 6 PIN

• Country Of Origin:

  Thailand

• Factory Lead Time:

  8 Weeks

• Manufacturer:

  Abracon Corporation

• YTEOL:

  5.88

• Additional Feature:

  TRI-STATE; ENABLE/DISABLE FUNCTION; TR, 7 INCH

• Fall Time-Max:

  2 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  25%

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  6

• Operating Frequency-Max:

  170 MHz

• Operating Frequency-Min:

  2.3 MHz

• Operating Frequency-Nom:

  25 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  CMOS

• Output Load:

  15 pF

• Output Low Current-Max:

  6 mA

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  DILCC6,.2

• Physical Dimension:

  7.0mm x 5.0mm x 0.85mm

• Qualification Status:

  Not Qualified

• Rise Time-Max:

  2 ns

• Supply Voltage-Max:

  3.6 V

• Supply Voltage-Min:

  2.25 V

• Surface Mount:

  YES

• Symmetry-Max:

  55/45 %

• Technology:

  CMOS
