ASVV-1.544MHZ-N152-T Details

• Manufacturer Part Number:

  ASVV-1.544MHZ-N152-T

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SMD, 6 PIN

• Factory Lead Time:

  14 Weeks

• Manufacturer:

  Abracon Corporation

• YTEOL:

  6

• Additional Feature:

  STANDBY; TRI-STATE; ENABLE/DISABLE FUNCTION

• Control Voltage-Max:

  3.15 V

• Control Voltage-Min:

  0.15 V

• Fall Time-Max:

  8 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Deviation/Pullability:

  150 ppm

• Frequency Stability:

  50%

• JESD-609 Code:

  e4

• Linearity:

  10%

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  6

• Operating Frequency-Nom:

  1.544 MHz

• Operating Temperature-Max:

  70 °C

• Oscillator Type:

  CMOS/TTL

• Output Load:

  5 TTL, 15 pF

• Package Equivalence Code:

  DILCC6,.2

• Packing Method:

  TR, 7 INCH

• Physical Dimension:

  7.0mm x 5.0mm x 2.0mm

• Rise Time-Max:

  8 ns

• Supply Current-Max:

  5 mA

• Supply Voltage-Max:

  3.465 V

• Supply Voltage-Min:

  3.135 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Symmetry-Max:

  40/60 %

• Terminal Finish:

  Gold (Au) - with Nickel (Ni) barrier
