AT25SF641-SUB-T - Adesto Technologies

Description: NOR Flash 64M 2.7V-3.6V SPI 104MHz IND TEMP

Download AT25SF641-SUB-T Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
AT25SF641-SUB-T - Adesto Technologies PCB footprint - Small Outline Packages - Small Outline Packages - SOP-8-
click to zoom
3D Models
AT25SF641-SUB-T - Adesto Technologies  - 3D model - Small Outline Packages - SOP-8-
click to zoom

AT25SF641-SUB-T Details

  • Manufacturer Part Number:

    AT25SF641-SUB-T

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Transferred

  • Package Description:

    SOIC-8

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.32.00.51

  • Manufacturer:

    Adesto Technologies Corporation

  • Clock Frequency-Max (fCLK):

    104 MHz

  • JESD-30 Code:

    S-PDSO-G8

  • JESD-609 Code:

    e1

  • Length:

    5.28 mm

  • Memory Density:

    67108864 bit

  • Memory IC Type:

    FLASH

  • Memory Width:

    8

  • Number of Functions:

    1

  • Number of Terminals:

    8

  • Number of Words:

    8388608 words

  • Number of Words Code:

    8000000

  • Operating Mode:

    SYNCHRONOUS

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Organization:

    8MX8

  • Output Characteristics:

    3-STATE

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Equivalence Code:

    SOP8,.3

  • Package Shape:

    SQUARE

  • Package Style:

    SMALL OUTLINE

  • Parallel/Serial:

    SERIAL

  • Programming Voltage:

    2.7 V

  • Seated Height-Max:

    2.16 mm

  • Serial Bus Type:

    QSPI

  • Supply Voltage-Max (Vsup):

    1.95 V

  • Supply Voltage-Min (Vsup):

    1.65 V

  • Supply Voltage-Nom (Vsup):

    1.8 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    TIN SILVER COPPER

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Type:

    NOR TYPE

  • Width:

    5.28 mm

  • Write Protection:

    HARDWARE/SOFTWARE

AT25SF641-SUB-T Frequently Asked Questions (FAQs)

  • The recommended operating voltage range for the AT25SF641-SUB-T is 2.7V to 3.6V.
  • The HOLD pin should be pulled high during power-up and power-down sequences to prevent unwanted writes to the device.
  • The AT25SF641-SUB-T supports up to 100,000 erase cycles.
  • Wear leveling can be implemented by distributing write cycles across the entire memory space, using techniques such as dynamic wear leveling or static wear leveling.
  • The WP pin is used to prevent writes to the status register and the memory array. When WP is low, the device is in write-protect mode.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

AT25SF641-SUB-T Overview

Use the download button to access the AT25SF641-SUB-T schematic symbol, PCB footprint, and 3D model.
