ATA01H18-L - Advanced Energy

Description: Artesyn Embedded Technologies ATA 6W Isolated DC-DC Converter Through Hole, Vin 9 → 36 V dc, Vout 24V dc

Download ATA01H18-L Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
ATA01H18-L - Advanced Energy PCB footprint - Other - Other - ATA01H18-L-2
click to zoom
3D Models
ATA01H18-L - Advanced Energy  - 3D model - Other - ATA01H18-L-2
click to zoom

ATA01H18-L Details

  • Manufacturer Part Number:

    ATA01H18-L

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • Factory Lead Time:

    14 Weeks

  • Manufacturer:

    Advanced Energy Industries Inc

  • Analog IC - Other Type:

    DC-DC REGULATED POWER SUPPLY MODULE

ATA01H18-L Frequently Asked Questions (FAQs)

  • The recommended PCB layout involves keeping the high-current paths short and wide, using multiple vias for heat dissipation, and placing the device on a thick copper layer. Thermal management involves using a heat sink with a thermal interface material, ensuring good airflow, and keeping the ambient temperature below 40°C.
  • To ensure reliable operation and minimize EMI, use a low-impedance power supply, decouple the input and output with capacitors, and use a common-mode choke or ferrite bead on the output. Additionally, follow proper PCB layout and grounding practices, and use shielding if necessary.
  • Exceeding maximum ratings can lead to device failure, reduced lifespan, or even catastrophic failure. To protect the device, use overvoltage protection (OVP) circuits, overcurrent protection (OCP) circuits, and thermal monitoring with shutdown or warning mechanisms. Ensure that the device is operated within the recommended specifications and follow proper derating guidelines.
  • To troubleshoot common issues, start by verifying the input voltage, output load, and PCB layout. Check for proper decoupling, grounding, and thermal management. Use an oscilloscope to analyze the output waveform and identify any oscillations or ringing. Consult the datasheet and application notes for guidance on specific troubleshooting procedures.
  • Operating the device in a high-humidity environment may lead to moisture-related issues, such as corrosion or electrical instability. In high-altitude environments, the device may experience reduced performance or reliability due to lower air pressure and oxygen levels. Ensure that the device is properly sealed, and consider using conformal coatings or potting compounds to protect against moisture. Consult the manufacturer's guidelines for operating the device in extreme environments.

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

ATA01H18-L Overview

Use the download button to access the ATA01H18-L schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like ATA01, or try a keyword search, such as Power Supply Modules
