ATSAMB11G18A-MU-Y - Microchip

Description: RF System on a Chip - SoC BLE 4.1 SOC Ultra Low Power

Download ATSAMB11G18A-MU-Y Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
ATSAMB11G18A-MU-Y - Microchip - PCB symbol
click to zoom
PCB Footprints
ATSAMB11G18A-MU-Y - Microchip PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - SAMB11 6x6 QFN 48
click to zoom
3D Models
ATSAMB11G18A-MU-Y - Microchip - 3D model - Quad Flat No-Lead - SAMB11 6x6 QFN 48
click to zoom

ATSAMB11G18A-MU-Y Details

  • Manufacturer Part Number:

    ATSAMB11G18A-MU-Y

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    QFN-48

  • ECCN Code:

    5A992.C

  • HTS Code:

    8542.31.00.01

  • Manufacturer:

    Microchip Technology Inc

  • YTEOL:

    0

  • JESD-30 Code:

    S-XQCC-N48

  • Length:

    5 mm

  • Number of Terminals:

    48

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    UNSPECIFIED

  • Package Code:

    VQCCN

  • Package Equivalence Code:

    LCC48,.24SQ,16

  • Package Shape:

    SQUARE

  • Package Style:

    CHIP CARRIER, VERY THIN PROFILE

  • Seated Height-Max:

    1 mm

  • Supply Voltage-Max:

    4.3 V

  • Supply Voltage-Min:

    2.3 V

  • Supply Voltage-Nom:

    3.3 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.4 mm

  • Terminal Position:

    QUAD

  • Width:

    5 mm

  • uPs/uCs/Peripheral ICs Type:

    RFSoC

ATSAMB11G18A-MU-Y Frequently Asked Questions (FAQs)

  • The recommended operating temperature range for the ATSAMB11G18A-MU-Y module is -40°C to +85°C.
  • The module's Wi-Fi and Bluetooth interfaces can be configured using the Microchip Advanced Software Framework (ASF) or the Microchip Harmony v3 software framework. These frameworks provide APIs and example code to configure and use the module's wireless interfaces.
  • The ATSAMB11G18A-MU-Y module supports a maximum data transfer rate of 150 Mbps for Wi-Fi and 2 Mbps for Bluetooth.
  • Yes, the ATSAMB11G18A-MU-Y module can be used with non-Microchip microcontrollers, but it may require additional development and testing to ensure compatibility. Microchip provides example code and documentation for using the module with Microchip microcontrollers, but it may not be directly applicable to other microcontrollers.
  • The ATSAMB11G18A-MU-Y module supports various security protocols, including WPA2, WPA3, and Bluetooth encryption. To secure the connections, you can use the Microchip-provided APIs and example code to implement encryption and authentication mechanisms, such as SSL/TLS, SSH, and HTTPS.
