ATV2500BQL-25PI - Microchip

ATV2500BQL-25PI Details

• Manufacturer Part Number:

  ATV2500BQL-25PI

• Part Life Cycle Code:

  Active

• Package Description:

  DIP-40

• HTS Code:

  8542.31.00.55

• Manufacturer:

  Microchip Technology Inc

• YTEOL:

  4

• Architecture:

  PLA-TYPE

• Clock Frequency-Max:

  27 MHz

• In-System Programmable:

  NO

• JESD-30 Code:

  R-PDIP-T40

• JTAG BST:

  NO

• Length:

  52.2 mm

• Number of Dedicated Inputs:

  13

• Number of I/O Lines:

  24

• Number of Inputs:

  38

• Number of Macro Cells:

  24

• Number of Outputs:

  24

• Number of Product Terms:

  416

• Number of Terminals:

  40

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Organization:

  13 DEDICATED INPUTS, 24 I/O

• Output Function:

  MACROCELL

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DIP

• Package Equivalence Code:

  DIP40,.6

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Programmable Logic Type:

  OT PLD

• Propagation Delay:

  22 ns

• Seated Height-Max:

  5.59 mm

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  4.5 V

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  NO

• Technology:

  CMOS

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Width:

  15.24 mm
