ATXP032-DWF - Adesto Technologies

ATXP032-DWF Details

• Manufacturer Part Number:

  ATXP032-DWF

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Package Description:

  DIE

• ECCN Code:

  EAR99

• HTS Code:

  8542.32.00.51

• Manufacturer:

  Adesto Technologies Corporation

• Clock Frequency-Max (fCLK):

  150 MHz

• Data Retention Time-Min:

  20

• Endurance:

  100000 Write/Erase Cycles

• JESD-30 Code:

  X-XUUC-N

• Memory Density:

  33554432 bit

• Memory IC Type:

  FLASH

• Memory Width:

  8

• Number of Functions:

  1

• Number of Words:

  4194304 words

• Number of Words Code:

  4000000

• Operating Mode:

  SYNCHRONOUS

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Organization:

  4MX8

• Output Characteristics:

  3-STATE

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DIE

• Package Equivalence Code:

  DIE OR CHIP

• Package Shape:

  UNSPECIFIED

• Package Style:

  UNCASED CHIP

• Parallel/Serial:

  SERIAL

• Serial Bus Type:

  SPI

• Standby Current-Max:

  0.000002 A

• Supply Current-Max:

  0.037 mA

• Supply Voltage-Max (Vsup):

  1.95 V

• Supply Voltage-Min (Vsup):

  1.7 V

• Supply Voltage-Nom (Vsup):

  1.8 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  NO LEAD

• Terminal Position:

  UPPER

• Type:

  NOR TYPE

• Write Protection:

  HARDWARE/SOFTWARE
