AUIRS21814S Details

  • Manufacturer Part Number:

    AUIRS21814S

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    ROHS COMPLIANT, MS-012AB, SOIC-14

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    Infineon Technologies AG

  • YTEOL:

    3

  • Built-in Protections:

    TRANSIENT; UNDER VOLTAGE

  • Interface IC Type:

    HALF BRIDGE BASED PERIPHERAL DRIVER

  • JESD-30 Code:

    R-PDSO-G14

  • JESD-609 Code:

    e3

  • Length:

    8.65 mm

  • Moisture Sensitivity Level:

    3

  • Number of Functions:

    1

  • Number of Terminals:

    14

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Current Flow Direction:

    SOURCE AND SINK

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    NOT SPECIFIED

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    1.75 mm

  • Supply Voltage-Max:

    20 V

  • Supply Voltage-Min:

    10 V

  • Supply Voltage-Nom:

    15 V

  • Surface Mount:

    YES

  • Temperature Grade:

    AUTOMOTIVE

  • Terminal Finish:

    Tin (Sn)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    NOT SPECIFIED

  • Turn-off Time:

    0.33 µs

  • Turn-on Time:

    0.27 µs

  • Width:

    3.9 mm

AUIRS21814S Frequently Asked Questions (FAQs)

  • Infineon provides a recommended PCB layout in the application note AN2014-01, which includes guidelines for thermal vias, copper thickness, and component placement to ensure optimal thermal performance.
  • The selection of a gate driver depends on the specific application requirements. Infineon recommends using a gate driver with a high current capability, such as the 2EDN7524F or the 1EDN8555F, and ensuring that the driver's output voltage is compatible with the AUIRS21814S's gate-source voltage rating.
  • According to Infineon's application note AN2014-01, the maximum allowed voltage imbalance between the high-side and low-side FETs is ±5V to ensure reliable operation and prevent damage to the device.
  • Infineon recommends using an external overcurrent protection circuit, such as a sense resistor and a comparator, to detect overcurrent conditions. The application note AN2014-01 provides a reference design for overcurrent protection.
  • The recommended dead time for the AUIRS21814S in a half-bridge configuration is typically in the range of 100-200 ns, depending on the specific application requirements and the switching frequency. A longer dead time can help prevent shoot-through currents, but may also increase switching losses.
