AWR1843ABGABLRQ1 - Texas Instruments

Description: RF System on a Chip - SoC Single-chip 76-GHz to 81-GHz automotive radar sensor integrating DSP, MCU and radar accelerator 161-FC/CSP -40 to 125

Download AWR1843ABGABLRQ1 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
AWR1843ABGABLRQ1 - Texas Instruments - PCB symbol
click to zoom
PCB Footprints
AWR1843ABGABLRQ1 - Texas Instruments PCB footprint - BGA - BGA - ABL0161B
click to zoom
3D Models
AWR1843ABGABLRQ1 - Texas Instruments - 3D model - BGA - ABL0161B
click to zoom

AWR1843ABGABLRQ1 Details

  • Manufacturer Part Number:

    AWR1843ABGABLRQ1

  • Brand Name:

    Texas Instruments

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.31.00.75

  • Date Of Intro:

    2019-07-03

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    15

  • Body Breadth:

    10.4 mm

  • Body Height:

    0.8 mm

  • Body Length or Diameter:

    10.4 mm

  • JESD-609 Code:

    e1

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Terminals:

    161

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Output:

    DIGITAL

  • Output Range:

    0.45-1.35V

  • Output Type:

    DIGITAL VOLTAGE

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Equivalence Code:

    BGA161,15X15,25

  • Package Shape/Style:

    SQUARE

  • Screening Level:

    AEC-Q100

  • Sensors/Transducers Type:

    RADAR SENSOR

  • Supply Voltage-Max:

    1.32 V

  • Supply Voltage-Min:

    1.14 V

  • Surface Mount:

    YES

  • Technology:

    RFCMOS

  • Terminal Finish:

    Tin/Silver/Copper (Sn/Ag/Cu)

AWR1843ABGABLRQ1 Frequently Asked Questions (FAQs)

  • The maximum range of the AWR1843ABGABLRQ1 is approximately 100 meters, depending on the environment and the type of objects being detected.
  • The AWR1843ABGABLRQ1 uses a combination of frequency modulation and pulse compression to mitigate multipath interference. Additionally, the device's built-in signal processing algorithms can help to reduce the effects of multipath interference.
  • Yes, the AWR1843ABGABLRQ1 can be used for gesture recognition applications. The device's high-resolution range and velocity data can be used to detect and track the movement of objects, allowing for the recognition of specific gestures.
  • The AWR1843ABGABLRQ1 has built-in noise reduction and interference mitigation mechanisms, including adaptive thresholding and filtering. Additionally, the device's signal processing algorithms can help to reduce the impact of noise and interference on the radar signal.
  • Yes, the AWR1843ABGABLRQ1 can be used in outdoor environments, but it may require additional protection and shielding to ensure reliable operation. The device's operating temperature range is -40°C to 85°C, making it suitable for use in a variety of outdoor environments.
