AWR1843ABSABLQ1 - Texas Instruments

Description: Texas Instruments Single-chip 76-GHz to 81-GHz automotive radar sensor integrating DSP, MCU and radar accelerator 161-FC/CSP -40 to 125

Download AWR1843ABSABLQ1 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
AWR1843ABSABLQ1 - Texas Instruments - PCB symbol
click to zoom
PCB Footprints
AWR1843ABSABLQ1 - Texas Instruments PCB footprint - BGA - BGA - ABL0161B
click to zoom
3D Models
AWR1843ABSABLQ1 - Texas Instruments - 3D model - BGA - ABL0161B
click to zoom

AWR1843ABSABLQ1 Details

  • Manufacturer Part Number:

    AWR1843ABSABLQ1

  • Brand Name:

    Texas Instruments

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    5A992.C

  • HTS Code:

    8542.31.00.75

  • Date Of Intro:

    2019-07-03

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    15

  • Body Breadth:

    10.4 mm

  • Body Height:

    0.8 mm

  • Body Length or Diameter:

    10.4 mm

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Terminals:

    161

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Output:

    DIGITAL

  • Output Range:

    0.45-1.35V

  • Output Type:

    DIGITAL VOLTAGE

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Equivalence Code:

    BGA161,15X15,25

  • Package Shape/Style:

    SQUARE

  • Screening Level:

    AEC-Q100

  • Sensors/Transducers Type:

    RADAR SENSOR

  • Supply Voltage-Max:

    1.32 V

  • Supply Voltage-Min:

    1.14 V

  • Surface Mount:

    YES

  • Technology:

    RFCMOS

AWR1843ABSABLQ1 Frequently Asked Questions (FAQs)

  • The maximum range of the AWR1843ABSABLQ1 radar sensor is approximately 100 meters, but this can vary depending on the environment, target size, and other factors.
  • The AWR1843ABSABLQ1 uses a combination of techniques such as frequency hopping, spatial diversity, and adaptive filtering to mitigate multipath interference.
  • Yes, the AWR1843ABSABLQ1 can be used for gesture recognition applications, such as detecting hand or body movements, due to its high-resolution range and velocity data.
  • The minimum distance between targets that the AWR1843ABSABLQ1 can detect is approximately 10-20 cm, depending on the target size and radar settings.
  • The AWR1843ABSABLQ1 uses a combination of techniques such as frequency hopping, adaptive filtering, and interference cancellation to mitigate noise and interference from other radar systems.
