AWR2944ABGALTQ1 - Texas Instruments

Description: Distance Sensors Automotive, second-generation 76-GHz to 81-GHz high-performance SoC for corner and long-range radar 266-FCCSP -40 to 140

Download AWR2944ABGALTQ1 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
AWR2944ABGALTQ1 - Texas Instruments - PCB symbol
click to zoom
PCB Footprints
AWR2944ABGALTQ1 - Texas Instruments PCB footprint - BGA - BGA - ALT0266A
click to zoom
3D Models
AWR2944ABGALTQ1 - Texas Instruments - 3D model - BGA - ALT0266A
click to zoom

AWR2944ABGALTQ1 Details

  • Manufacturer Part Number:

    AWR2944ABGALTQ1

  • Brand Name:

    Texas Instruments

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.31.00.75

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    15

  • Body Breadth:

    12 mm

  • Body Height:

    0.738 mm

  • Body Length or Diameter:

    12 mm

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Terminals:

    266

  • Operating Temperature-Max:

    140 °C

  • Operating Temperature-Min:

    -40 °C

  • Output:

    OPEN-DRAIN

  • Output Range:

    0.45-1.35V

  • Output Type:

    DIGITAL VOLTAGE

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Equivalence Code:

    BGA266,18X18,25

  • Package Shape/Style:

    SQUARE

  • Screening Level:

    AEC-Q100

  • Sensors/Transducers Type:

    MMWAVE RADAR SENSOR MODULE

  • Supply Voltage-Max:

    1.26 V

  • Supply Voltage-Min:

    1.14 V

  • Surface Mount:

    YES

  • Technology:

    RFCMOS

AWR2944ABGALTQ1 Frequently Asked Questions (FAQs)

  • The maximum operating temperature range for the AWR2944ABGALTQ1 is -40°C to 125°C.
  • The AWR2944ABGALTQ1 has built-in interference mitigation techniques, such as frequency hopping and adaptive thresholding, to minimize the impact of interference from other radar systems.
  • Yes, the AWR2944ABGALTQ1 can be used for other applications such as industrial radar, surveillance, and robotics, although it is primarily designed for automotive radar applications.
  • The minimum distance that the AWR2944ABGALTQ1 can detect objects is approximately 0.5 meters, depending on the specific application and configuration.
  • The AWR2944ABGALTQ1 uses advanced signal processing algorithms to mitigate multipath effects, including adaptive filtering and beamforming techniques.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

AWR2944ABGALTQ1 Overview

Use the download button to access the AWR2944ABGALTQ1 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like AWR29, or try a keyword search, such as Other Sensors/Transducers
