AX5DBF1-400.0000T footprint, schematic symbol and 3D model by ABRACON

Symbol

PCB Footprints

3D Models

AX5DBF1-400.0000T Details

Abracon recommends following the IPC-7351B standard for PCB land patterns. A specific land pattern recommendation can be found in the Abracon Crystal Oscillator Layout Guide, which is available on their website.
To ensure the oscillator starts up correctly, Abracon recommends following proper PCB design and layout guidelines, using a suitable power supply, and ensuring the oscillator is properly terminated. Additionally, the oscillator should be driven from a low-impedance source, and the load capacitance should be within the recommended range.
The AX5DBF1-400.0000T has an operating temperature range of -40°C to +85°C. However, it's essential to note that the oscillator's frequency stability and accuracy may be affected at extreme temperatures.
The AX5DBF1-400.0000T is designed to operate in environments with moderate vibration. However, if your application involves high vibration, Abracon recommends consulting their application notes and considering additional mechanical support or vibration isolation measures to ensure reliable operation.
Abracon recommends storing the AX5DBF1-400.0000T in a dry, cool place, away from direct sunlight and moisture. The storage temperature should be between -40°C and +30°C, and the relative humidity should be below 60%.

Manufacturer Collaborated

System Verified

Community Approved

Use the download button to access the AX5DBF1-400.0000T schematic symbol, PCB footprint, and 3D model.

To find more CAD model downloads similar to this part, try a partial part number search, like AX5DB, or try a keyword search, such as XO
