AX8052F143-3-TB05 - onsemi

Description: RF Microcontroller, Ultra-low Power

Download AX8052F143-3-TB05 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
AX8052F143-3-TB05 - onsemi PCB footprint - Quad Flat No-Lead - Quad Flat No-Lead - QFN40 7x5, 0.5P CASE 485EG ISSUE A
click to zoom
3D Models
AX8052F143-3-TB05 - onsemi  - 3D model - Quad Flat No-Lead - QFN40 7x5, 0.5P CASE 485EG ISSUE A
click to zoom

AX8052F143-3-TB05 Details

  • Manufacturer Part Number:

    AX8052F143-3-TB05

  • Brand Name:

    ON Semiconductor

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Manufacturer Package Code:

    485EG

  • HTS Code:

    8542.31.00.30

  • Manufacturer:

    onsemi

  • YTEOL:

    0

  • JESD-30 Code:

    R-PQCC-N40

  • JESD-609 Code:

    e4

  • Length:

    7 mm

  • Moisture Sensitivity Level:

    1

  • Number of Terminals:

    40

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HVQCCN

  • Package Equivalence Code:

    LCC28,.35X.55

  • Package Shape:

    RECTANGULAR

  • Package Style:

    CHIP CARRIER, VERY THIN PROFILE, HEAT SINK/SLUG

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    1 mm

  • Supply Voltage-Max:

    3.6 V

  • Supply Voltage-Min:

    2.2 V

  • Supply Voltage-Nom:

    3 V

  • Surface Mount:

    YES

  • Technology:

    CMOS

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)

  • Terminal Form:

    NO LEAD

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    QUAD

  • Width:

    5 mm

  • uPs/uCs/Peripheral ICs Type:

    RFSOC

AX8052F143-3-TB05 Frequently Asked Questions (FAQs)

  • The recommended operating voltage range for the AX8052F143-3-TB05 is 2.2V to 3.6V.
  • To configure the AX8052F143-3-TB05 for low-power mode, set the PWRDN pin high and ensure that the VDDIO pin is connected to a voltage source within the recommended operating range.
  • The AX8052F143-3-TB05 supports a maximum clock frequency of 143 MHz.
  • To implement a watchdog timer using the AX8052F143-3-TB05, use the internal watchdog timer (WDT) module, which can be configured to generate a reset signal if the timer expires.
  • The VDDIO pin on the AX8052F143-3-TB05 is used to power the I/O buffers and should be connected to a voltage source within the recommended operating range.
