A thermal pad on the bottom of the package is recommended for heat dissipation. A minimum of 2oz copper thickness and a thermal relief pattern on the PCB are also recommended.
Ensure proper thermal management, follow recommended PCB layout guidelines, and consider using a thermal interface material (TIM) to improve heat transfer between the device and heat sink.
Follow the recommended soldering profile: peak temperature 260°C, time above 217°C 60s, and time above 200°C 150s. Use a solder with a melting point above 217°C.
Yes, but ensure proper mounting and mechanical stress relief. The component is designed to withstand vibrations up to 10G. Consult the datasheet for specific vibration testing conditions.
Follow standard ESD handling procedures: use an ESD wrist strap, mat, or workstation, and ensure all equipment is grounded. The component has built-in ESD protection, but handling precautions are still necessary.
Trust Checks
This model has been provided by an expert contributor.
Expert Contribution
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
AXT436124 Overview
Use the download button to access the AXT436124 schematic symbol and PCB footprint.
To find more CAD model downloads similar to this part, try a partial part number search, like AXT43,
or try a keyword search, such as Headers and Edge Type Connectors
