B82625B2202M001 - TDK

B82625B2202M001 Details

• Manufacturer Part Number:

  B82625B2202M001

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  RADIAL LEADED

• Country Of Origin:

  India, Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Manufacturer:

  TDK Corporation

• YTEOL:

  6

• Construction:

  Rectangular

• Core Material:

  IRON POWDER

• DC Resistance:

  0.42 Ω

• Inductance-Nom (L):

  1200 µH

• Inductor Application:

  POWER INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• JESD-609 Code:

  e3

• Number of Functions:

  2

• Number of Terminals:

  4

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Height:

  30 mm

• Package Length:

  44 mm

• Package Style:

  Radial

• Package Width:

  42.4 mm

• Packing Method:

  Tray

• Rated Current-Max:

  2 A

• Shape/Size Description:

  RECTANGULAR PACKAGE

• Shielded:

  NO

• Special Feature:

  INDUCTANCE IS MEASURED AT 0.1 mA

• Surface Mount:

  NO

• Terminal Finish:

  TIN OVER NICKEL

• Terminal Placement:

  RADIAL

• Terminal Shape:

  FLAT

• Test Frequency:

  0.01 MHz

• Tolerance:

  20%
