B82746S6702A040 - TDK

B82746S6702A040 Details

• Manufacturer Part Number:

  B82746S6702A040

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  India

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Manufacturer:

  TDK Corporation

• YTEOL:

  7

• Construction:

  Cylindrical

• Core Material:

  FERRITE

• DC Resistance:

  0.018 Ω

• Inductance-Nom (L):

  6200 µH

• Inductor Application:

  POWER INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• JESD-609 Code:

  e3

• Lead Diameter:

  1.25 mm

• Lead Length:

  3.5 mm

• Number of Functions:

  3

• Number of Terminals:

  6

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Diameter:

  52 mm

• Package Length:

  39 mm

• Package Style:

  PCB Mount

• Packing Method:

  Tray

• Rated Current-Max:

  8 A

• Shape/Size Description:

  DISK PACKAGE

• Shielded:

  NO

• Special Feature:

  INDUCTANCE IS MEASURED AT 0.1 MILLI AMPERE

• Surface Mount:

  NO

• Terminal Finish:

  TIN

• Terminal Placement:

  RADIAL

• Terminal Shape:

  SPECIAL

• Test Frequency:

  0.01 MHz

• Tolerance:

  50%
