BA5406 - ROHM Semiconductor

BA5406 Details

• Manufacturer Part Number:

  BA5406

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SFM

• Package Description:

  ROHS COMPLIANT, SIP-12

• Pin Count:

  12

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Manufacturer:

  ROHM Semiconductor

• YTEOL:

  0

• Consumer IC Type:

  AUDIO AMPLIFIER

• Gain:

  46 dB

• Harmonic Distortion:

  10%

• JESD-30 Code:

  R-XSFM-T12

• JESD-609 Code:

  e2

• Number of Channels:

  2

• Number of Functions:

  1

• Number of Terminals:

  12

• Operating Temperature-Max:

  75 °C

• Operating Temperature-Min:

  -20 °C

• Output Power-Nom:

  5 W

• Package Body Material:

  UNSPECIFIED

• Package Code:

  SFM

• Package Equivalence Code:

  SIP12,.1

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Peak Reflow Temperature (Cel):

  260

• Qualification Status:

  Not Qualified

• Supply Current-Max:

  70 mA

• Supply Voltage-Max (Vsup):

  15 V

• Supply Voltage-Min (Vsup):

  5 V

• Surface Mount:

  NO

• Technology:

  BIPOLAR

• Temperature Grade:

  COMMERCIAL EXTENDED

• Terminal Finish:

  Tin/Copper (Sn/Cu)

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  SINGLE
