BA6956AN - ROHM Semiconductor

BA6956AN Details

• Manufacturer Part Number:

  BA6956AN

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  SIP

• Package Description:

  ROHS COMPLIANT, SIP-9

• Pin Count:

  9

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  ROHM Semiconductor

• YTEOL:

  0

• Analog IC - Other Type:

  3-PHASE BRUSHLESS DC MOTOR CONTROLLER

• JESD-30 Code:

  R-PSIP-T9

• JESD-609 Code:

  e2

• Length:

  21.8 mm

• Number of Functions:

  1

• Number of Terminals:

  9

• Operating Temperature-Max:

  75 °C

• Operating Temperature-Min:

  -20 °C

• Output Current-Max:

  1 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SIP

• Package Equivalence Code:

  SIP9,.05

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Peak Reflow Temperature (Cel):

  260

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  7.2 mm

• Supply Current-Max (Isup):

  80 mA

• Supply Voltage-Max (Vsup):

  15 V

• Supply Voltage-Min (Vsup):

  6.5 V

• Supply Voltage-Nom (Vsup):

  9 V

• Surface Mount:

  NO

• Technology:

  BIPOLAR

• Temperature Grade:

  COMMERCIAL EXTENDED

• Terminal Finish:

  Tin/Copper (Sn/Cu)

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  SINGLE

• Width:

  2.8 mm
