BCM384T480M325B00 - VICOR

BCM384T480M325B00 Details

• Manufacturer Part Number:

  BCM384T480M325B00

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-60

• ECCN Code:

  EAR99

• Manufacturer:

  Vicor Corporation

• YTEOL:

  8

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CURUS, CTUVUS,CE

• Control Mode:

  VOLTAGE-MODE

• Efficiency (Main Output):

  96%

• Input Voltage-Max:

  400 V

• Input Voltage-Min:

  360 V

• Input Voltage-Nom:

  384 V

• JESD-30 Code:

  R-XQMA-T60

• Length:

  32.5 mm

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  60

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Output Current-Max:

  10.5 A

• Output Voltage-Max:

  50 V

• Output Voltage-Min:

  45 V

• Output Voltage-Nom:

  48 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  QMA

• Package Shape:

  UNSPECIFIED

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE; THERMAL

• Ripple Voltage (Main Out):

  0.1414 Vrms

• Seated Height-Max:

  6.98 mm

• Surface Mount:

  NO

• Switching Frequency-Max:

  1730 kHz

• Technology:

  HYBRID

• Temperature Grade:

  MILITARY

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  QUAD

• Total Power Output-Max:

  325 W

• Trim/Adjustable Output:

  NO

• Width:

  22 mm
