BCR25CM-12LB#BB0 - Renesas Electronics

Description: BCR25CM-12LB#BB0 Renesas Electronics, TRIAC 25A, Gate Trigger 2V 50mA, 3-Pin TO-220AB

Download BCR25CM-12LB#BB0 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
BCR25CM-12LB#BB0 - Renesas Electronics - PCB symbol
click to zoom
PCB Footprints
BCR25CM-12LB#BB0 - Renesas Electronics PCB footprint - Transistor Outline, Vertical - Transistor Outline, Vertical - PRSS0004AG-A
click to zoom
3D Models
BCR25CM-12LB#BB0 - Renesas Electronics - 3D model - Transistor Outline, Vertical - PRSS0004AG-A
click to zoom

BCR25CM-12LB#BB0 Details

  • Manufacturer Part Number:

    BCR25CM-12LB#BB0

  • Brand Name:

    Renesas

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Part Package Code:

    TO-220AB

  • Pin Count:

    4

  • Manufacturer Package Code:

    PRSS0004AG

  • ECCN Code:

    EAR99

  • Factory Lead Time:

    4 Weeks

  • Manufacturer:

    Renesas Electronics Corporation

  • YTEOL:

    0

  • Critical Rate of Rise of Commutation Voltage-Min:

    1 V/us

  • DC Gate Trigger Current-Max:

    50 mA

  • DC Gate Trigger Voltage-Max:

    2 V

  • Operating Temperature-Max:

    150 °C

  • Operating Temperature-Min:

    -40 °C

  • Packing Method:

    TUBE

  • RMS On-state Current-Max:

    25 A

  • Repetitive Peak Off-state Voltage:

    600 V

  • Surface Mount:

    NO

  • Trigger Device Type:

    TRIAC
