BD00D0AWHFP - ROHM Semiconductor

BD00D0AWHFP Details

• Manufacturer Part Number:

  BD00D0AWHFP

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  MODULE

• Package Description:

  ROHS COMPLIANT, HRP-5

• Pin Count:

  5

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  ROHM Semiconductor

• YTEOL:

  6.8

• Dropout Voltage1-Max:

  0.55 V

• JESD-30 Code:

  R-PSSO-G5

• Length:

  9.395 mm

• Number of Functions:

  1

• Number of Terminals:

  5

• Operating Temperature TJ-Max:

  105 °C

• Operating Temperature TJ-Min:

  -20 °C

• Output Current1-Max:

  2 A

• Output Voltage1-Max:

  15 V

• Output Voltage1-Min:

  3 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HSOP

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, HEAT SINK/SLUG

• Peak Reflow Temperature (Cel):

  260

• Qualification Status:

  Not Qualified

• Regulator Type:

  ADJUSTABLE POSITIVE SINGLE OUTPUT LDO REGULATOR

• Seated Height-Max:

  2.135 mm

• Surface Mount:

  YES

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.72 mm

• Terminal Position:

  SINGLE

• Width:

  8 mm
