BD7679G-GTR - ROHM Semiconductor

Description: Switching Controllers PWM Control Type DC/DC Converter IC for AC/DC Driver,

Download BD7679G-GTR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
BD7679G-GTR - ROHM Semiconductor PCB footprint - SOT23 (6-Pin) - SOT23 (6-Pin) - SSOP 6
click to zoom
3D Models
BD7679G-GTR - ROHM Semiconductor  - 3D model - SOT23 (6-Pin) - SSOP 6
click to zoom

BD7679G-GTR Details

  • Manufacturer Part Number:

    BD7679G-GTR

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    ROHM Semiconductor

  • YTEOL:

    6

  • Analog IC - Other Type:

    SWITCHING CONTROLLER

  • Control Mode:

    CURRENT-MODE

  • Control Technique:

    PULSE WIDTH MODULATION

  • Input Voltage-Max:

    26 V

  • Input Voltage-Min:

    8.5 V

  • Input Voltage-Nom:

    12 V

  • JESD-30 Code:

    R-PDSO-G6

  • Length:

    2.9 mm

  • Number of Functions:

    1

  • Number of Terminals:

    6

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Current-Max:

    1 A

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    LSSOP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, LOW PROFILE, SHRINK PITCH

  • Packing Method:

    TR

  • Seated Height-Max:

    1.25 mm

  • Surface Mount:

    YES

  • Switcher Configuration:

    SINGLE

  • Switching Frequency-Max:

    65 kHz

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.95 mm

  • Terminal Position:

    DUAL

  • Width:

    1.6 mm

BD7679G-GTR Frequently Asked Questions (FAQs)

  • The recommended operating voltage range for the BD7679G-GTR is 2.5V to 5.5V.
  • To ensure stability, it's recommended to use a 1μF or larger ceramic capacitor for the output capacitor (COUT) and a 1μF or larger ceramic capacitor for the input capacitor (CIN).
  • The maximum output current of the BD7679G-GTR is 1.5A.
  • To handle thermal design, ensure a sufficient heat dissipation path, and consider the thermal resistance (θja) of the package. A thermal pad or heat sink may be necessary for high-power applications.
  • The EN (enable) pin is used to turn the regulator on or off. When EN is high, the regulator is enabled, and when EN is low, the regulator is disabled.
