ROHM recommends a thermal pad on the bottom of the package, connected to a large copper area on the PCB to dissipate heat efficiently. A 4-layer PCB with a solid ground plane and thermal vias is also recommended.
To ensure stable operation with a high-ESR output capacitor, add a 1-10nF ceramic capacitor in parallel with the output capacitor to reduce the overall ESR. Additionally, consider using a low-ESR output capacitor or a capacitor with a built-in ESR reduction feature.
The maximum allowed voltage on the EN pin is 6V, which is higher than the recommended operating voltage of 5V. However, it's essential to ensure that the EN pin voltage does not exceed the maximum rating to prevent damage to the device.
The BD8325FVT-ME2 is rated for operation up to 105°C, but it's essential to consider the derating of the output current and power dissipation at high temperatures. Consult the datasheet and ROHM's application notes for guidance on high-temperature operation.
To troubleshoot oscillations or instability issues, check the PCB layout, component selection, and soldering quality. Ensure that the input and output capacitors are properly selected and placed, and that the feedback network is correctly implemented. Consult ROHM's application notes and technical support for further guidance.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
BD8325FVT-ME2 Overview
Use the download button to access the BD8325FVT-ME2 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like BD832,
or try a keyword search, such as Switching Regulator or Controllers
